Room Temperature Sensor
ROOM TEMPERATURE SENSOR
STH Branded Room Temperature NTC Thermistor Sensor is a precision temperature-sensing device designed to measure ambient (room) temperature in indoor environments such as homes, offices, and electronic systems.
These sensors are typically placed in air-exposed locations (not embedded in materials), allowing them to detect surrounding air temperature quickly and reliably.
Our group of professionals check and examine our premium line of STTS Series Sensors on different required parameters. We offer Room Temperature Sensors at nominal prices to make a long-term relationship with our esteemed customers.
Applications
Room temperature sensing in air conditioners
Automotive Climate control systems
Indoor air monitoring systems in Building Automation
Ambient sensing in Refrigerators
OPTIONS AVAILBLE UPON REQUEST
Encapsulation types: epoxy coated, glass encapsulated bead, metal housing (immersion sensors), chip version.
Lead types: insulated wire leads, bare leads,PTFE, silicone, high‑temp lead wires.
Tolerance classes: ±1%, ±3% on Resistance Value and ±1% or ±2% on Beta Value depending on product cost/accuracy.
Lead wire available options: insulated wire leads, bare leads,PTFE, silicone, high‑temp lead wires Lead length, cable gauge, connector type can be customised
RT CHARACTERISTICS (RESISTANCE & BETA VALUES)
| Resistance At 25°C (Ω) | Beta Value (25/85) (K) | |||
| 2000 | 3540 | |||
| 2057 | 3540 | |||
| 2800 | 3900 | |||
| 3000 | 3977 | |||
| 4700 | 3977 | |||
| 5000 | 3977 | |||
| 10000 | 3977 | |||
| Resistance At 25°C (Ω) | Beta Value (25/85) (K) |
| 20000 | 4000 |
| 30000 | 4050 |
| 47000 | 4100 |
| 49300 | 3960 |
| 50000 | 4100 |
| 100000 | 4400 |
| 170000 | 4250 |
* Customization can be possible
